61804576 | LAPP
Straight hose fitting, M12, 10 mm, polyamide, IP66/IP67/IP68/IP69, gray
Order No.: 33P5758
EAN: 4044778395445
MPN:
61804576
FIPLOCK ONE METALL XL M12X1,5 / 10 GY
Series: FIPLOCK ONE Metal M
Unit Price (€ / pc.)
13.0662 € *
Available: 0 pcs.
Leadtime: 6 Weeks **
Hose fitting, 61804576, LAPP
The 61804576 is a conduit fitting system for highest requirements, suitable for FIPLOCK PA6 / PA12. This product has very high tensile strength due to all around tooth system and ensures mounting safety due to integrated coding system.
Features
- Good chemical resistance
- Flame-retardant
- Halogen-free
- Cold-resistant
- Maximum vibration protection
- Mechanical resistance
- Assembly time
- Low weight
Applications
- Demand of increased liquid tightnes
- For indoor and outdoor use
Technical specifications
| Colour | gray | |
| Thread size | M12 | |
| Material | polyamide | |
| max. operating temperature | 120 °C | |
| min. operating temperature | -45 °C | |
| Nominal width | 10 mm | |
| Degree of protection (IP) | IP66/IP67/IP68/IP69 |
Download
Logistics
| Customs tariff number | 39174000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
