61804473 | LAPP
90° hose fitting, M50, 36 mm, polyamide, IP66/IP67/IP68/IP69, black, (L) 90.8 mm
Order No.: 33P5681
EAN: 4044778394493
MPN:
61804473
FIPLOCK ONE 90°-B M50X1,5 / 36 BK
Series: FIPLOCK ONE 90° M
Unit Price (€ / pc.)
40.8289 € *
Available: 0 pcs.
Leadtime: 6 Weeks **
Hose fitting, 61804473, LAPP
The 61804473 is a conduit fitting system for highest requirements, suitable for FIPLOCK PA6 / PA12. This product has very high tensile strength due to all around tooth system and ensures mounting safety due to integrated coding system.
Features
- Good chemical resistance
- Flame-retardant
- Halogen-free
- Cold-resistant
- Maximum vibration protection
- Mechanical resistance
- Assembly time
- Low weight
Applications
- Demand of increased liquid tightnes
- For indoor and outdoor use
Technical specifications
| Colour | black | |
| Thread size | M50 | |
| Length | 90.8 mm | |
| Material | polyamide | |
| max. operating temperature | 120 °C | |
| min. operating temperature | -45 °C | |
| Nominal width | 36 mm | |
| Degree of protection (IP) | IP66/IP67/IP68/IP69 |
Download
Logistics
| Customs tariff number | 39174000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
