16001053 | LAPP
Rubber connection cable H07RN-F 4 G 2.5 mm², unshielded, black, 16001053
Unit Price (€ / mtr.)
3.4629 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
3.46 € *
Price list
Quantity
Price per unit*
1 mtr.
3.4629 €
10 mtr.
3.1773 €
50 mtr.
2.9631 €
100 mtr.
2.7846 €
500 mtr.
2.5942 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power and control cable, 16001053, LAPP
The 16001053 designed for use subject to high mechanical load conditions in dry or damp rooms, suitable for outdoor use. Continuous operational movements, restricted guidance, usage of these cables in moving cable carriers or on motor drum guidance or under a strain of more than 15 N/mm² conductor cross section are not allowed.
Features
- Cold-resistant
- Mechanical resistance
- Oil-resistant
- UV-resistant
Technical specifications
| Core insulation material | rubber | |
| Colour | black | |
| Number of cores | 4 | |
| Protective conductor available | Yes | |
| Outer diameter | 13.8 mm | |
| Drag chain suitable | No | |
| Test voltage | 2.5 kV | |
| Halogen free | No | |
| Cable cross-section | 2.5 mm² | |
| Version | connection line | |
| Material | rubber | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Rated voltage U0 | 450 V | |
| Temperature range (unmoved) | -25 °C to 60 °C | |
| Temperature range (active) | -25 °C to 60 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 750 V |
Download
Logistics
| Country of origin | RO |
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
