0042022 | LAPP
PVC ribbon cable ÖLFLEX LIFT F 20 G 1.0 mm², unshielded, black, 0042022
Order No.: 33P5003
EAN: 4044774664996
MPN:
0042022
ÖLFLEX LIFT F 20G1 300/500V
Series: ÖLFLEX LIFT F
Unit Price (€ / mtr.)
8.6513 € *
Standard delivery time from the manufacturer is: On Request
Flat cable, 0042022, LAPP
The 0042022 is a cold flexible PVC flat cable for flexible use under medium mechanical load conditions, suitable for outdoor use if the indicated temperature range is observed. This product is largely resistant to acids and certain oils at room temperature. It is suitable for linear movements, such as occur in elevators and power chains. The maximum tensile load is 15 N/mm² of conductor cross-section during installation and operation. Compulsory guidance is not permitted.
Features
- Flame-retardant
- Flat cables need less space than round cables
Applications
- Indoor cranes and high-rack facilities
- As supply line for moving machine parts
- For hoisting equipment and conveyor systems
Technical specifications
| Cable material | copper, bright | |
| Colour | black | |
| Shielding | unshielded | |
| Halogen free | No | |
| Cable cross-section | 1.0 mm² | |
| Drag chain suitable | No | |
| Version | flat cable | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Standard number | VDE | |
| Core insulation material | PVC | |
| Temperature range (active) | -0 °C to 70 °C | |
| Material | PVC | |
| Number of cores | 20 | |
| Protective conductor available | Yes | |
| Conductor category | CL.6 = finest stranded | |
| Outer diameter | 59 mm | |
| Test voltage | 3 kV |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
