0042003 | LAPP
PVC ribbon cable ÖLFLEX LIFT F 7 G 1.5 mm², unshielded, black, 0042003
Order No.: 33P5014
EAN: 4044774664484
MPN:
0042003
ÖLFLEX LIFT F 7G1,5 450/750V
Series: ÖLFLEX LIFT F
Unit Price (€ / mtr.)
4.9504 € *
Standard delivery time from the manufacturer is: 6 Weeks
Flat cable, 0042003, LAPP
The 0042003 is a cold flexible PVC flat cable for flexible use under medium mechanical load conditions, suitable for outdoor use if the indicated temperature range is observed. This product is largely resistant to acids and certain oils at room temperature. It is suitable for linear movements, such as occur in elevators and power chains. The maximum tensile load is 15 N/mm² of conductor cross-section during installation and operation. Compulsory guidance is not permitted.
Features
- Flame-retardant
- Flat cables need less space than round cables
Applications
- Indoor cranes and high-rack facilities
- As supply line for moving machine parts
- For hoisting equipment and conveyor systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | flat cable | |
| Conductor category | CL.6 = finest stranded | |
| Number of cores | 7 | |
| Shielding | unshielded | |
| Core insulation material | PVC | |
| Test voltage | 3 kV | |
| Cable cross-section | 1.5 mm² | |
| Temperature range (active) | -15 °C to 70 °C | |
| Standard number | VDE | |
| Rated voltage U0 | 450 V | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| Outer diameter | 27 mm | |
| Colour | black | |
| Rated voltage | 750 V | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
