3698 | Klauke
Insulated Wire end ferrule, 0.5 mm², 13 mm/8 mm long, DIN 46228/4, white, 3698
Order No.: 18H7420
EAN: 4012078023566
MPN:
3698
Unit Price (€ / pc.)
0.2237 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
0.22 € *
Price list
Quantity
Price per unit*
1000 pcs.
0.2237 €
5000 pcs.
0.2011 €
*incl. VAT plus shipping costs
**Subject to prior sale
Wire end ferrule, 3698, KLAUKE
Insulated wire-end ferrule with lug, for fine and superfine stranded conductors, according to DIN EN 60228 Cl. 5 and 6, with marking system for max. 6 marking rings. Dimensions according to DIN 46228 part 4.
Features
- Halogen free
- Tin plated to protect against corrosion
Technical specifications
| Colour | white | |
| Material Insulation | polypropylene | |
| Isolated | Yes | |
| Contact material | copper | |
| Length | 13 mm | |
| Cable cross-section | 0.5 mm² | |
| max. operating temperature | 105 °C | |
| Standard number | DIN 46228/4 | |
| Pin lenght | 8 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
