L-59SURKCGKW-CA | Kingbright
LED, THT, Ø 5 mm, red/green, 80 mcd to 12 cd, 60°, L-59SURKCGKW-CA
Active
Total price
(
0.4403 €
* / pcs.)
4.40 €
Available: 200 pcs.
Quantity
Price per unit*
10 pcs.
0.4403 €
50 pcs.
0.3808 €
250 pcs.
0.3451 €
1000 pcs.
0.2975 €
2000 pcs.
0.2678 €
*incl. VAT plus
shipping costs
Please send price/quantity requests to info@buerklin.com
Description
Product by Kingbright at Bürklin Elektronik
LED, L-59SURKCGKW-CA, Kingbright
The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode
Features
- Uniform light output
- Low power consumption
- 3 leads with one common lead
Technical specifications
| Radiation angle | 60 ° | |
| Number of LEDs | 2 | |
| On-State Voltage | 2.5 V | |
| Forward Current | 20 mA | |
| diameter | 5 mm | |
| Colour of the LED | red/green | |
| Length | 8.6 mm | |
| Light intensity min. | 0.08 cd | |
| Light intensity typ. | 12 cd | |
| Lens | white | |
| Assembly | THT |
Logistics
| Country of origin | CN |
| Customs tariff number | 85414100 |
| MSL | MSL 1 |
| Original Packaging | Bag with 500 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
Download
Variations
Order No.:
66S9261
Manufacturer:
Kingbright
Manufacturer SKU
L-59EGW
10 pcs.
0.6069 €
50 pcs.
0.5236 €
250 pcs.
0.4522 €
1000 pcs.
0.4046 €
2000 pcs.
0.3689 €
6.07 € *
Available: 331 pcs.
0.06 cd
0.565 µm
-40 °C
0.02 cd
5 mm
60 °
30 mA
white
8.6 mm
2.5 V
THT
red/green
85 °C
Order No.:
72S7026
Manufacturer:
Kingbright
Manufacturer SKU
L-59SURKCGKW-CA
10 pcs.
0.4403 €
50 pcs.
0.3808 €
250 pcs.
0.3451 €
1000 pcs.
0.2975 €
2000 pcs.
0.2678 €
4.40 € *
Available: 200 pcs.
12 cd
0.08 cd
5 mm
60 °
20 mA
white
8.6 mm
2.5 V
THT
red/green
Order No.:
72S5431
Manufacturer:
Kingbright
Manufacturer SKU
L-59SURKCGKC
1000 pcs.
0.2392 €
2.8 cd
-40 °C
24 °
2.1 V
THT
red/green
85 °C
Order No.:
72S7027
Manufacturer:
Kingbright
Manufacturer SKU
L-59SURKMGKW
10 pcs.
0.5712 €
50 pcs.
0.4998 €
250 pcs.
0.4284 €
1000 pcs.
0.3808 €
2000 pcs.
0.3451 €
5.71 € *
Available: 849 pcs.
0.7 cd
0.65 µm
-40 °C
0.05 cd
5 mm
60 °
20 mA
white
8.6 mm
2.5 V
THT
red/green
85 °C
Order No.:
72S5417
Manufacturer:
Kingbright
Manufacturer SKU
L-59EGC
25 pcs.
0.2951 €
125 pcs.
0.2630 €
500 pcs.
0.2368 €
2000 pcs.
0.2154 €
5000 pcs.
0.1975 €
7.38 € *
Available: 995 pcs.
0.2 cd
-40 °C
20 °
clear
2.5 V
THT
red/green
85 °C
