Linear solenoid, RM 050W-OBOO-N-24VDC, 100 % duty cycle
Unit Price (€ / pc.)
246.3895 € *
Available: 0 pcs.
Leadtime: On Request **
Heavy-duty linear solenoids, type Kuhnke RM 050.
Without stroke limit. Combination solenoid (pull and thrust solenoid), maintenance-free armature bearing (DU bearing) for highest demands; Rated stroke: 10 mm. Rated voltage: 24 VDC. Rated power: 20 W. Initial force: 13 N. Final force: 25 N. Approved relative duty cycle: 100 %. Connection: 6.3 mm crimp terminals or 200 mm stranded wire. Insulation class: F. Temperature limit: +155 °C. Test voltage: 2500 VRMS. Solenoid weight: approx. 610 g. Armature weight: approx. 200 g.
With 6.3 mm crimp terminals, type RM 050.
Type: RM 050W-OBOO-N-24VDC, linear solenoid, 100 % duty cycle
Technical specifications
| Initial force | 13 N | |
| Connection | stranded wires | |
| On Period | 100 % ED | |
| Final force | 25 N | |
| Stroke | 10 mm | |
| Power | 20 W | |
| Rated voltage (DC) | 24 V | |
| Return spring | No |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85059029 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
