217082800 | Kabeltronik
PUR control line 2-PURtronic-C-UL twisted pair (TP) 10-wire, AWG 28, shielded, black
Unit Price (€ / mtr.)
4.0341 € *
Available: 0 mtr.
Available in 7 Days: 4,970 mtr.
Leadtime: 1 Week **
Total Price:
4.03 € *
Price list
Quantity
Price per unit*
100 mtr.
4.0341 €
200 mtr.
3.8794 €
800 mtr.
3.6295 €
*incl. VAT plus shipping costs
**Subject to prior sale
Control cable, 217082800, KABELTRONIK
The used PUR jacket material is exellent steady against hydrolysis, low temperature and microorganism.
FEATURES
- Oil-resistant
- Low temperature flexible
- Halogen-free
Technical Data
- Color: black
- AWG cross-sectionAWG 28
- Material: PUR
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Core insulation material | PUR | |
| Number of cores | 10 | |
| Version | control line | |
| Outer diameter | 6.4 mm | |
| AWG cross-section | AWG 28 | |
| Colour | black | |
| Halogen free | Yes | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, bright | |
| Material | PUR | |
| Rated voltage | 600 V | |
| Test voltage | 3 kV | |
| Shielding | shielded | |
| Temperature range (active) | -30 °C to 80 °C | |
| Temperature range (unmoved) | -50 °C to 80 °C |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444995 |
| Original Packaging | Ring with 100 meters |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
