010202500 | Kabeltronik
PVC control line LiYY 2 x 0.25 mm², unshielded, gray, 010202500
NCNR (non cancelable / non returnable)
Unit Price (€ / mtr.)
0.9520 € *
Available: 29 mtr.
Available in 7 Days: 5,000 mtr. - if ordered today
Total Price:
0.95 € *
Price list
Quantity
Price per unit*
1 mtr.
0.9520 €
10 mtr.
0.7973 €
100 mtr.
0.7259 €
500 mtr.
0.6664 €
1000 mtr.
0.5831 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC control cable, 010202500, Kabeltronik
High flexibility and small outside diameter characterise this cable. Suitable for measuring-, signal, control-, and regulation technology as well as call plants and data processing.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | control line | |
| Number of cores | 2 | |
| Cable cross-section | 0.25 mm² | |
| Colour | gray | |
| Material | PVC | |
| Outer diameter | 4 mm | |
| Shielding | unshielded | |
| Halogen free | No | |
| Cable material | copper, bright | |
| Core insulation material | PVC | |
| Core colour sequence | DIN 47100 | |
| Rated voltage | 900 V | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Test voltage | 2.5 kV |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85444995 |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
