ZHR-2 | JST
Socket housing, 2 pole, pitch 1.5 mm, straight, natural, ZHR-2
Unit Price (€ / pc.)
0.0238 € *
Available: 0 pcs.
Leadtime: 30 Weeks **
Steckverbinder 1,5 mm Serie ZH Typ JST.
In kompakter Bauform, zuverlässige Kontaktkonstruktion; Nennstrom: 1,0 AUC, Nennspannung: 50 V AC/DC, Spannungsfestigkeit: 500 VAC (60 s), Kontaktwiderstand (Anfangswert): max. 20 mOhm, Isolationswiderstand: min. 500 MOhm, Temperaturbereich: –25 bis +85 °C. Zulassungen: TÜV, UL, CSA.
Buchsengehäuse unbestückt.
Material Gehäuse: PA 66, UL 94 V-0, Farbe: natur (weiß). Tabellenangaben: Typ, Polzahl, Maß A, Maß B.
Type: ZHR-2, 2-polig, A 1,5 mm, B 4,5 mm
Technical specifications
| Connection | crimp connection | |
| Connection plating | tin-plated | |
| Number of rows | 1 | |
| Version | socket housing | |
| Additional parts | equipped | |
| Colour | natural | |
| Contact type | socket | |
| contact surface | tin-plated | |
| Rated voltage | 50 V | |
| Rated current | 1 A | |
| Orientation | straight | |
| Pin number | 2 pole | |
| Grid | 1.5 mm |
Download
Logistics
| Country of origin | KR |
| Customs tariff number | 85472000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
