PBV-R200-F1-0.5 | Isabellenhütte
Metal film resistor, 200 mΩ, 3 W, ±0.5 %, PBV-R200-F1-0.5
Unit Price (€ / pc.)
14.0539 € *
Available: 319 pcs.
Total Price:
14.05 € *
Price list
Quantity
Price per unit*
1 pcs.
14.0539 €
10 pcs.
12.7806 €
100 pcs.
11.9357 €
500 pcs.
11.0551 €
1000 pcs.
10.5315 €
*incl. VAT plus shipping costs
Subject to prior sale
Radial, type PBV-R200-F1-0.5, Isabellenhütte
FEATURES
- 4-terminal connection
- Pulse power rating 2 J for 10 ms
- Excellent long-term stability
Technical Data
- Power: 3 W
- Tolerance: ±1 %
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Isolation voltage | 500 V | |
| Height | 17.5 mm | |
| Length | 22.5 mm | |
| Power | 3 W | |
| Temperature coefficient | 30 ppm/K | |
| nominal load capacity without cooling surface | 10 W | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -55 °C | |
| Version | precision metal film resistor | |
| Assembly | THT | |
| Width | 4.45 mm | |
| Design | radial | |
| Tolerance | ±0.5 % | |
| ohmic resistance | 200 mΩ |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Original Packaging | Bar with 25 pieces |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
