SMK-R010-1.0 | Isabellenhütte

Resistor, metal foil, SMD 1206 (3216), 10 mΩ, 1 W, ±1 %, SMK-R010-1.0

Order No.: 09E252
EAN: 4099879202499
MPN:
SMK-R010-1.0
Series: SMK
SMK-R010-1.0 Isabellenhütte SMD Resistors Image 1
SMK-R010-1.0 Isabellenhütte SMD Resistors Image 2
Image may differ
Unit Price (€ / pc.)
1.9873 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
1.99 € *
Price list
Quantity
Price per unit*
1 pcs.
1.9873 €
10 pcs.
1.4161 €
100 pcs.
1.2138 €
500 pcs.
1.0472 €
1000 pcs.
0.9520 €
*incl. VAT plus shipping costs
Subject to prior sale

SMD precision resistors, size 1206, 1.0 W, series ISA-PLAN, type Isabellenhütte SMK.

Suitable for use as shunt resistance in switching mode power supplies, power modules, frequency converters, and control units

1.0 % tolerance.

Technical specifications
Filter Property Value
max. operating temperature 170 °C
Width 1.6 mm
ohmic resistance 10 mΩ
Height 0.5 mm
Temperature coefficient ±50 ppm/K
Power 1 W
Technology metal foil
Tolerance ±1 %
min. operating temperature -65 °C
Design SMD 1206 (3216)
Length 3.05 mm
Logistics
Property Value
Country of origin DE
Customs tariff number 85332100
Original Packaging Reel with 5,000 pieces
Compliance
Property Value
SVHC free Yes
RoHS conform Yes
Date of RoHS guidelines 3/31/15
