54512.2L-CPR | INFRALAN

FO cable U-DQ(ZN)BH 12G 50/125µ, OM4,LSZH black CPR Dca

Order No.: 26P1494
EAN: 4049759180645
MPN:
54512.2L-CPR
INFRALAN
default L
front L
Image may differ
Unit Price (€ / mtr.)
2.8322 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: 1 Week **
Total Price:
2.83 € *
*incl. VAT plus shipping costs
**Subject to prior sale
2000 mtr.
2.8322 €

FO cable, 54512.2L-CPR, INFRALAN

The 54512.2L-CPR is a universale cable suitable for connector assembly, fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function Not suitable for underground laying (direct buried).

Technical specifications
Number of fibres 12
Outer diameter 7 mm
Colour black
Chamfer type multimode 50/125 µm
Halogen free Yes
Category OM4
Material LSZH
Temperature range (active) -25 °C to 70 °C
Temperature range (unmoved) -20 °C to 60 °C
Logistics
Customs tariff number 85447000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
1 item in 4 variations
*incl. VAT plus shipping costs
