XE161FL20F66VAAKXUMA1 | Infineon Technologies
C166SV2 microcontroller, 16 bit, 66 MHz, VFQFN-48, XE161FL20F66VAAKXUMA1
Unit Price (€ / pc.)
4.76 € *
Standard delivery time from the manufacturer is: On Request
Microcontroller, XE161FL20F66VAAKXUMA1, INFINEON
The XE161FL20F66VAAKXUMA1 16 Bit Single-Chip Real Time Signal Controller is a full-feature singlechip CMOS microcontroller. This device extends the functionality and performance in terms of instructions (MAC unit), peripherals, and speed.
Features
- High Performance 16 bit CPU with 5-Stage Pipeline
- On-chip bootstrap loaders
- Single power supply from 3.0 V to 5.5 V
- Two capture/compare units for flexible PWM signal generation (CCU6x)
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of I/Os | 33 | |
| Number of pins | 48 | |
| Processor core | C166SV2 | |
| Enclosure | VFQFN-48 | |
| Clock frequency | 66 MHz | |
| Voltage | 3-5.5 V | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -40 °C | |
| Version | flash | |
| Assembly | SMD | |
| Core Size | 16 bit | |
| Data RAM Size | 12 KB | |
| Memory size | 160 KB |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 2,500 pieces |
| Customs tariff number | 85423190 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
