0 522 269 | Hengstler
Incremental encoder, 5 V, 0 522 269
Active
Product by Hengstler at Bürklin Elektronik
Incremental encoders, type Hengstler RI 58-O.
General-purpose rotary encoder for industrial applications, high shock loads and signal precision, with synchronization flange; Supply voltage RS422 + alarm: 5.0 VDC ±10 %. Shaft diameter: 6.0 mm. Shaft load: radial 40 N, axial 20 N. Speed: max. 10000 rpm. Torque: max. 0.5 N/cm. Degree of protection case/shaft entry: IP 65/IP 64. Operating temperatures: –10 to +70 °C. Connection type: 1.5 m PVC cable, radial. Case material: aluminum, D 58 mm. Weight: approx. 360 g.
Technical attributes (type, resolution or number of measuring steps (divisions) within a measuring range): RI 58-O/1000AS.41RB, 1000
| Version | Incremental encoder | |
| Voltage | 5 V |
| Country of origin | DE |
| Customs tariff number | 90291000 |
| RoHS conform | Yes |
| Date of RoHS guidelines | 6/8/11 |
| SVHC free | Yes |
