09120033016 | Harting
Pin contact insert, 3A, 2 pole, equipped, IDC connection, 09120033016
Unit Price (€ / pc.)
20.8369 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Contact insert, 09 12 003 3016, Harting
Insert, Male, Polycarbonate (PC), RAL 7032 (pebble grey), Rated current: 10 A, Size: 3 A, Contacts: 2, + RJ45
Technical Data
- Contact design: Pin Insert
- Material: Thermoplastic
- Shell size: 3A
- min. Operating temperature: -40 °C
- max. Operating temperature: 125 °C
- Rated current: 10 A
- Rated voltage: 24 V
- PE contact: No
Technical specifications
| Version | pin insert | |
| Additional parts | equipped | |
| Shell size | 3A | |
| Contact connection | IDC connection | |
| PE contact | No | |
| Pin number | 2 pole | |
| Special Contacts | RJ45 |
Download
Logistics
| Country of origin | RO |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
