PSU 600-2.6 | GW Instek
(0~600V/ 0~2.6A / 1560W) Single Channel Programmable Switching DC Power Supply Type PSU 600-2.6
Programmable Switching DC Power Supply, PSU 600-2.6, GW Instek
The PSU 600-2.6 is a DC power supply with high power density design, is 1U in height and compatible with 19” rack mount size. The PSU 600-2.6 is suitable for test system installation or system integration by flexibly selecting a model for the integration into the existing test system. The PSU, featuring superior voltage and current control function, comprises fifteen model with output voltage/current ranging from 6V/200A to 600V/2.6A. The PSU 600-2.6 is suitable for different test condition and DUT, including electronic component testing, micro resistor, relay, shunt resistor, 12V/24V/48V battery simulation, and automotive electronic device testing. The PSU 600-2.6 is ideal for the primary input of DC/DC converter and servomotor production application. PSU 600-2.6 is often integrated into component test system such as aging test equipment for capacitor; 600V DC bias application; aging test equipment for diode; semiconductor production equipment; automotive electronic; and ECU for V8 engine or V12 engine, etc.
Features
- Adjustable voltage/current rise and fall time
- High Efficiency and High Power Density
| Property | Value |
|---|---|
| Customs tariff number | 85044085 |
| Country of origin | TW |
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
