GPE-1326A | GW Instek
Laboratory power supply, 0 bis 32 V, outputs: 1 (6 A), 0 to 6 A, 192 W, GPE-1326A
Unit Price (€ / pc.)
379.61 € *
Standard delivery time from the manufacturer is: On Request
Single Channel Programmable DC Power Supply, GPE-1326A, GW Instek
The GPE-1326A DC power supply is the latest iteration of the GPE-1326, building upon its proven quality and reputation. This upgraded model refines precision with an encoder switch for more accurate voltage and current adjustment. Additionally, the digital control system has been streamlined-reducing four rotary knob to just two-enhancing the front panel’s simplicity and ease of operation. A key improvement in this iteration is the overvoltage protection (OVP). Unlike the previous GPE, which relied on a single maximum voltage threshold for activation, the new A version allows OVP voltage setting from 1 V to 36 V.
Features
- Output ON/OFF
- Analog Control (Remote I/O) for Output ON / OFF
- Key Lock Function
- Smart cooling fan achieving low noise
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 210 mm | |
| Range of Output Currence | 0 to 6 A | |
| Height | 155 mm | |
| Output current | 6 A | |
| Depth | 306 mm | |
| Number of outputs | 1 | |
| Power | 192 W | |
| Output voltage DC | 0 to 32 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044085 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
