9625000000B | GMW
Panel-mount instrument, Front panel, Moving-iron mechanism, AC/DC, 9625000000B
Order No.: 15K250
EAN: 4099891453893
MPN:
9625000000B
EQB96 250V
Unit Price (€ / pc.)
49.0042 € *
Standard delivery time from the manufacturer is: 1 Week
Display instruments, type GMW EQB.
Moving iron instrument to safety standard EN 61010, for DC and AC current and voltage, with black slim-line bezel to DIN 43718; Case material: polycarbonate, self-extinguishing and non-dripping to UL 94 V-0. Glass: glare resistant. Tolerance class: 1.5. Scaling: rough-fine. Inherent power consumption: at current/voltage 0.6 to 0.8 VA/2.5 VA. Degree of protection: IP 52. Operating position: vertical. Mounting depth: without/with covers 53/66 mm.
With bezel dimensions of 96 x 96 mm, type EQB 96.
Mounting cutout: 92 x 92 mm. Scale length: 97 mm. Operating voltage: max. 250 V. Test voltage: 5.8 kV. Weight: 250 g
Type: 96250 00000 B, 250 V
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height of cut-out | 92 mm | |
| AC or DC measurement possible | AC | |
| Width of cut-out | 92 mm | |
| max. Voltage | 250 V | |
| Height | 96 mm | |
| Width | 96 mm | |
| Installation depth | 66 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 90303370 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
