7225000000B | GMW
Panel-mount instrument, Front panel, Moving-iron mechanism, AC/DC, 7225000000B
Order No.: 15K232
EAN: 4099891453879
MPN:
7225000000B
EQB72 250V
Unit Price (€ / pc.)
30.2736 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
30.27 € *
Price list
Quantity
Price per unit*
1 pcs.
30.2736 €
5 pcs.
21.9912 €
*incl. VAT plus shipping costs
Subject to prior sale
Display instruments, type GMW EQB.
Moving iron instrument to safety standard EN 61010, for DC and AC current and voltage, with black slim-line bezel to DIN 43718; Case material: polycarbonate, self-extinguishing and non-dripping to UL 94 V-0. Glass: glare resistant. Tolerance class: 1.5. Scaling: rough-fine. Inherent power consumption: at current/voltage 0.6 to 0.8 VA/2.5 VA. Degree of protection: IP 52. Operating position: vertical. Mounting depth: without/with covers 53/66 mm.
With bezel dimensions of 72 x 72 mm, type EQB 72.
Mounting cutout: 68 x 68 mm. Scale length: 63 mm. Operating voltage: max. 600 V. Test voltage: 5.8 kV. Weight: 200 g.
Type: 72250 00000 B, 250 V
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Installation depth | 66 mm | |
| Width | 72 mm | |
| Height of cut-out | 68 mm | |
| Assembly | front panel mounting | |
| Height | 72 mm | |
| Width of cut-out | 68 mm | |
| AC or DC measurement possible | AC/DC | |
| max. Voltage | 600 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 90303370 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
