PLCC 28 | Fischer Elektronik

Chip socket, 28 pole, pitch 2.54 mm , CuSn-alloy for PLCC

Order No.: 15B5270
EAN: 4099879023568
MPN:
PLCC 28
Series: PLCC
Fischer Elektronik
default L
Image may differ
Unit Price (€ / pc.)
1.3209 € *
Available: 128 pcs.
Leadtime: 1 Week **
Total Price:
1.32 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
1.3209 €

Chip sockets, type Fischer PLCC.

For PLCCs with package design to standard EiA/JEDEC Type A; Insulating body: PBT GF, UL 94 V-0. Contact material: nickel-plated phosphor bronze, additionally tinned. Rated current: 1.0 A. Rated voltage: 125 VDC. Operating temperatures: –55 to +110 °C. Features: with drainage holes for better internal cleaning, mold with test holes next to each contact spring. Double polarity indication.

Technical attributes (number of poles, length (L), width (W), mounting height (H)): 28-pole, L 18.1, W 18.1, H 8.2 mm

Technical specifications
Version Chip socket
Width 18.1 mm
Suitable for PLCC
Height 8.2 mm
Contact material CuSn-alloy
Length 18.1 mm
Material Polyphenylene sulfide/Glass fiber
max. operating temperature 105 °C
min. operating temperature -40 °C
Rated current 1 A
Pin number 28 pole
Grid 2.54 mm
Logistics
Country of origin TW
Customs tariff number 85369095
Original Packaging Bar with 33 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
Width
Length
Pin number
Material
Version
Grid
Contact material
Height
Suitable for
min. operating temperature
max. operating temperature
Rated current
1 item in 6 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
Width
Length
Pin number
Material
Version
Grid
Contact material
Height
Suitable for
min. operating temperature
max. operating temperature
Rated current
Chip socket, 44 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5272
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 10007423
Available: 265 pcs. Leadtime: 13 Weeks **
Total Price: 3.05 € *
1 pcs.
3.0464 €
25 pcs.
2.5823 €
100 pcs.
2.3919 €
250 pcs.
2.2610 €
1000 pcs.
2.0825 €
23.2 mm
23.2 mm
44 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
Chip socket, 28 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5270
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 PLCC 28
Available: 128 pcs. Leadtime: 1 Week **
Total Price: 1.32 € *
1 pcs.
1.3209 €
18.1 mm
18.1 mm
28 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
Chip socket, 68 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5274
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 10007427
Available: 281 pcs. Leadtime: 13 Weeks **
Total Price: 3.40 € *
1 pcs.
3.4034 €
19 pcs.
2.8917 €
114 pcs.
2.5585 €
266 pcs.
2.4276 €
1007 pcs.
2.2372 €
30.8 mm
30.8 mm
68 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
Chip socket, 32 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5271
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 10007419
Available: 117 pcs. Leadtime: 9 Weeks **
Total Price: 1.44 € *
1 pcs.
1.4399 €
20.7 mm
18.1 mm
32 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
Chip socket, 52 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5273
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 10007425
Available: 190 pcs. Leadtime: 8 Weeks **
Total Price: 3.19 € *
1 pcs.
3.1892 €
25 pcs.
2.7013 €
100 pcs.
2.4990 €
250 pcs.
2.3681 €
1000 pcs.
2.1777 €
25.7 mm
25.7 mm
52 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
Chip socket, 84 pole, pitch 2.54 mm , CuSn-alloy for PLCC
Order No.:
 15B5276
Manufacturer:
 Fischer Elektronik
Manufacturer SKU:
 10007429
Available: 137 pcs. Leadtime: 13 Weeks **
Total Price: 3.75 € *
1 pcs.
3.7485 €
16 pcs.
3.2963 €
112 pcs.
2.9750 €
256 pcs.
2.8560 €
1008 pcs.
2.6894 €
36 mm
36 mm
84 pole
Polyphenylene sulfide/Glass fiber
Chip socket
2.54 mm
CuSn-alloy
8.2 mm
PLCC
-40 °C
105 °C
1 A
