22.72.0.024.1517 | Finder
Contactor, 2 pole, 32 A, 230 VAC, 1 Form A (N/O) + 1 Form B (N/C), coil 24 V AC/DC, screw connection, 22.72.0.024.1517
Order No.: 34G1293
EAN: 8012823435060
MPN:
22.72.0.024.1517
227200241517
Unit Price (€ / pc.)
38.3775 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
38.38 € *
Price list
Quantity
Price per unit*
1 pcs.
38.3775 €
3 pcs.
36.8424 €
5 pcs.
35.4263 €
*incl. VAT plus shipping costs
Subject to prior sale
Modular contactor, 22.72.0.024.1517, Finder
Installation contactor for 35 mm rail, 1 NO contact and 1 NC contact for 32 A / 400 V AC, NC contact as mirror contact, in accordance with EN 60947-4-1, contact material AgNi, max. switching capacities at 230 V AC: AC1 7000 VA, 1-phase motor load, AC3 (230 V AC) 1.3 kW, energy-saving lamps 250 W, LED (230 V AC) 300 W, LV halogen lamps or LED with electronic ballast 300 W, LV halogen lamps or LED with electronic ballast 500 W. Coil 24 V AC/DC, width 17.5 mm, with mechanical switch position indicator, relay protection class: IP 20.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | 1 Form A (N/O) + 1 Form B (N/C) | |
| Control Voltage | 24 V AC/DC | |
| Degree of protection (IP) | IP20 | |
| Version | installation contactor | |
| Rated current | 32 A | |
| Rated Voltage | 230 VAC | |
| Pin number | 2 pole | |
| Assembly | DIN rail | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | SI |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
