284740-E | ERNI
Panel plug, M12, 5 pole, SMD, straight, 284740-E
Order No.: 59F009
MPN:
284740-E
M12 MALE, A CODE, 5P, 10.5MM SMT
Unit Price (€ / pc.)
8.4133 € *
Standard delivery time from the manufacturer is: 39 Weeks
Total Price:
8.41 € *
Price list
Quantity
Price per unit*
1 pcs.
8.4133 €
10 pcs.
7.8897 €
50 pcs.
7.4256 €
100 pcs.
7.1043 €
*incl. VAT plus shipping costs
Subject to prior sale
M12 sensor-actuator connector, 284740-E, ERNI
Cable-to-Board, Circular Connector Plug, 5 Position, Printed Circuit Board, Power, Signal & High Speed Data, Board Mount, Code A, M12 Connector.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | panel plug | |
| Version | 10.5 mm | |
| Pin number | 5 pole | |
| Thread size | M12 | |
| Coding | A | |
| Orientation | straight | |
| Contact connection | SMD | |
| Additional parts | equipped | |
| Assembly | PCB mounting | |
| Degree of protection (IP) | IP65/IP67 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
