DEP 16201-W | Display Elektronik
OLED-PLED Display 2x16 - PM-OLED White DEP 16201-W
Order No.: 71S206
EAN: 4099879007278
MPN:
DEP 16201-W
Unit Price (€ / pc.)
28.4648 € *
Available: 0 pcs.
Leadtime: On Request **
TFT-Display, DEP 16201-W, Display Elektronik
General Specifications
- Module Dimension: 80.00 x 36.00 x 10.00 (max.) mm
- Viewing Area: 66.00 x 16.00 mm
- Active Area: 56.95 x 11.85 mm
Technical specifications
| Display | 16 x 2 character | |
| Viewing area (width) | 16 mm | |
| Viewing range (height) | 66 mm | |
| Width | 36 mm | |
| Thickness | 10 mm | |
| Shell size | 80 x 36 x 10 mm | |
| type of backlight | OLED | |
| Background color | white | |
| Height | 80 mm | |
| IC controller/driver | HD44780 compatible | |
| Lifetime | 50.000 hours | |
| Light intensity typ. | 60 cd | |
| max. operating temperature | 80 °C | |
| min. operating temperature | -40 °C | |
| MPU interface | 8-Bit-MCU | |
| Technology | OLED | |
| Character height | 5.55 mm | |
| Character set | English-Japanese, English-European, English-Cyrillic |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85249200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
