EL100D10-24 | CRYDOM
Solid state relay, 100 VDC, 21-27 VDC, 10 A, EL100D10-24
Unit Price (€ / pc.)
65.9141 € *
Available: 0 pcs.
Leadtime: 31 Weeks **
Total Price:
65.91 € *
Price list
Quantity
Price per unit*
2 pcs.
65.9141 €
9 pcs.
62.3560 €
18 pcs.
60.7733 €
20 pcs.
59.4524 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solid-state relays, type Crydom EL.
For installation in control cabinets, with tab terminals (input 4.8 mm, output 6.3 mm); Operating temperatures: –30 to +80 °C. Certifications: cUL. Dimensions: 21 x 21 x 15 mm (without flange and connections).
With MOSFET output and 3.0 to 100 VDC output voltage.
Technical attributes (type, output voltage, output current, control voltage): EL100D10-24, 10 A, 21 to 27 VDC
Technical specifications
| LED display | No | |
| Rated current | 10 A | |
| Voltage V RRM (peak reverse voltage) | 600 V | |
| Voltage | 21-27 VDC | |
| Control Voltage | 100 VDC |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
