DC100D40C | CRYDOM
Solid state relay, 100 VDC, 4-32 VDC, 40 A, PCB mounting, DC100D40C
Unit Price (€ / pc.)
156.0328 € *
Available: 0 pcs.
Available in 5 Days: 8 pcs.
Leadtime: 1 Week **
Total Price:
156.03 € *
Price list
Quantity
Price per unit*
1 pcs.
156.0328 €
4 pcs.
129.2102 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solid State Relay, DC100D40C, CRYDOM
Solid State Relay, Panel Mount, IP20, 100VDC/40A, 4-32VDC In, FET Output
Features
- Ratings from 10 A to 100 A @ 100 VDC
- LED Status Indicator
- Relays are easily paralleled for higher-current applications
- UL Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- Mosfet Output
- DC control
- EMC Compliant to Level 3
- Epoxy Free Design
- Optional IP20 Cover
Technical specifications
LED display | Yes | |
Assembly | PCB mounting | |
Rated current | 40 A | |
Voltage | 4-32 VDC | |
Control Voltage | 100 VDC |
Download
Logistics
Country of origin | MX |
Customs tariff number | 85364900 |
Compliance
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
