CKRD4810 | CRYDOM
Solid state relay, 48-530 VAC, zero voltage switching, 4.5-32 VDC, 10 A, DIN rail, CKRD4810
Unit Price (€ / pc.)
130.1503 € *
Available: 1 pcs.
Leadtime: 31 Weeks **
Total Price:
130.15 € *
Price list
Quantity
Price per unit*
1 pcs.
130.1503 €
3 pcs.
126.2471 €
10 pcs.
121.9036 €
25 pcs.
118.6549 €
100 pcs.
113.4427 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solid State Relay, CKRD4810, CRYDOM
SSR Relay, DIN Rail Mount 22.5mm, 530VAC/10A, 4.5-32VDC In, Zero Cross
Features
- Rating from 10 A to 30 A @ 280 VAC
- Slim 22.5 mm (width) package
- SCR output for heavy industrial loads
- LED input status indicator
- AC or DC control
- Zero Voltage (resistive loads) or Instantaneous (inductive loads) turn-on output
Technical specifications
LED display | Yes | |
Assembly | DIN rail | |
Rated current | 10 A | |
Switching Mode | zero voltage switching | |
Voltage V RRM (peak reverse voltage) | 600 V | |
Voltage | 4.5-32 VDC | |
Control Voltage | 48-530 VAC |
Download
Logistics
Country of origin | MX |
Customs tariff number | 85364900 |
Compliance
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
