19350231 | CML
Signal light, 230 V (AC), green, 11 mcd, Mounting Ø 14 mm, LED number: 1, 19350231
Unit Price (€ / pc.)
12.8401 € *
Available: 71 pcs.
Total Price:
128.40 € *
Price list
Quantity
Price per unit*
10 pcs.
12.8401 €
30 pcs.
12.1856 €
50 pcs.
11.8048 €
*incl. VAT plus shipping costs
Subject to prior sale
LED signal lamps, type CML 1935.
Panel-mount diameter: 14 mm. LED diameter: 10 mm, with high-gloss chrome plated brass reflector and protective sleeve. Connection: tab terminals 2.8 x 0.8 mm. Degree of protection (EN 60529): IP 67, at the front between the LED and housing, and between the housing and front panel if the included seal ring is used. Ambient temperatures: –20 to +60 °C. Certifications: VDE, UL.
Technical attributes (type, rated voltage, color, rated current, luminous intensity): 19350231, 230 VAC, green, 3.0 mA, 11 mcd
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 230 V | |
| Rated current | 3 mA | |
| Luminous intensity | 0.011 cd | |
| Connection | faston plug 2.8 x 0.8 mm | |
| Diode Diameter | 10 mm | |
| Number of LEDs | 1 | |
| Farbe der Beleuchtung | green | |
| Assembly | central Mounting | |
| Installation diameter | 14 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85414100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
