PX0931/03/S | BULGIN
Panel plug, 3 pole, screw connection, screw locking, straight, PX0931/03/S
Unit Price (€ / pc.)
18.2189 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Circular connector series 900, type Bulgin PX09.
With screw terminals; Contact resistance: max. 10 mohm. Material: polyamide to UL 94 V-0. Contacts: nickel-plated brass. Degree of protection: IP 68. Operating temperatures: –40 to +85 °C. Certifications: CSA (rated current 25 to 30 A), UL, VDE, CCC (rated current 10 to 32 A).
Front panel connectors with female contacts, type PX0931.
Technical attributes (type, number of poles, rated voltage/current): PX0931/03/S, 3-pole, 600 V AC/DC/32 A
Technical specifications
| Version | panel plug | |
| Additional parts | equipped | |
| Shell Material | polyamide | |
| Contact connection | screw connection | |
| contact surface | nickel-plated | |
| Assembly | PCB mounting | |
| Orientation | straight | |
| Pin number | 3 pole | |
| Type of locking | screw locking |
Download
Logistics
| Country of origin | TN |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
