ISOM5-250-B-L2 | Bourns Electronics GmbH
Hybrid protection component, radial, 10000 A, 320 V (DC), 250 V (AC), ISOM5-250-B-L2
Unit Price (€ / pc.)
2.1301 € *
Available: 144 pcs.
Total Price:
2.13 € *
Price list
Quantity
Price per unit*
1 pcs.
2.1301 €
25 pcs.
1.8088 €
300 pcs.
1.5232 €
600 pcs.
1.4518 €
1200 pcs.
1.3804 €
*incl. VAT plus shipping costs
Subject to prior sale
Varistor series IsoMOV
By combining the best features of both MOV and GDT technologies in a single component, the IsoMOV™ series achieves high performance with low capacitance, very low leakage current and excellent power handling density. The IsoMOV™ series is ideally suited for AC and DC power supply applications where highest performance and/or space savings are required.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 250 V | |
| Rated voltage (DC) | 320 V | |
| Design | radial | |
| max. Surge current, transient (8/20 µs) | 10000 A | |
| min. operating temperature | -40 °C | |
| Standard number | UL, CSA | |
| max. operating temperature | 125 °C | |
| Grid | 7.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 300 pieces |
| MSL | MSL 1 |
| Customs tariff number | 85334090 |
| Country of origin | CR |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
