Name: Cermet trimmer potentiometer, 25 turns, 10 kΩ, 0.5 W, THT, lateral, 3296Z-1-103LF
Brand: Bourns Electronics GmbH
SKU: 76E2818
Price: 2.74 EUR
Availability: InStock

Cermet trimmer potentiometer, 25 turns, 10 kΩ, 0.5 W, THT, lateral, 3296Z-1-103LF

Order No.: 76E2818

EAN: 4099879894519

MPN:

3296Z-1-103LF

Series: 3296Z

Image may differ

Key Specification:

Version cermet trimmer potentiometer

ohmic resistance 10 kΩ

Tolerance ±10 %

Power 0.5 W

Assembly THT

Show 15 variants

Download Datasheet Technical specifications
