CRA2512-FZ-R020ELF | Bourns Electronics GmbH

Resistor, thick film, SMD 2512 (6330), 20 mΩ, 3 W, ±1 %, CRA2512-FZ-R020ELF

Order No.: 07E2922
EAN: 4099879176196
MPN:
CRA2512-FZ-R020ELF
Series: CRA2512
Bourns Electronics GmbH
default L
Image may differ
Print
Key Specification:
ohmic resistance 20 mΩ
Tolerance ±1 %
Power 3 W
Design SMD 2512 (6330)
Show 14 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
0.5831 € *
Available: 3,912 pcs.
Leadtime: 14 Weeks **
Total Price:
5.83 € *
Price list
Quantity
Price per unit*
10 pcs.
0.5831 €
50 pcs.
0.4760 €
250 pcs.
0.4046 €
1000 pcs.
0.3451 €
2500 pcs.
0.3070 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Resistor, CRA2512-FZ-R020ELF, BOURNS

High power current sense chip resistor.

Features

  • Inductance less than 5 nH
  • RoHS compliant

Applications

  • Power supplies
  • Stepper motor drives
  • Input amplifiers
Technical specifications
ohmic resistance 20 mΩ
Design SMD 2512 (6330)
Width 3 mm
Height 0.7 mm
Length 6.45 mm
Power 3 W
max. operating temperature 170 °C
min. operating temperature -55 °C
Tolerance ±1 %
Technology thick film
Temperature coefficient ±50 ppm/K
Show similar products 0
Logistics
Country of origin TW
Customs tariff number 85332100
MSL MSL 1
Original Packaging Reel with 4,000 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
ohmic resistance
Unit:
Tolerance
Design
Width
Unit:
Length
Unit:
Height
Unit:
min. operating temperature
max. operating temperature
Power
Unit:
Technology
1 item in 14 variations
*incl. VAT plus shipping costs
Item description
Total
Price list
ohmic resistance
Tolerance
Design
Width
Length
Height
min. operating temperature
max. operating temperature
Power
Technology
Resistor, thick film, SMD 2512 (6330), 100 mΩ, 3 W, ±1 %, CRA2512-FZ-R100ELF
Resistor, thick film, SMD 2512 (6330), 100 mΩ, 3 W, ±1 %, CRA2512-FZ-R100ELF
Order No.:
 07E2931
Manufacturer:
 Bourns Electronics GmbH
Manufacturer SKU:
 CRA2512-FZ-R100ELF
Available: 7,318 pcs. Leadtime: 14 Weeks **
Total Price: 0.62 € *
1 pcs.
0.6188 €
50 pcs.
0.4522 €
250 pcs.
0.3689 €
500 pcs.
0.3332 €
1000 pcs.
0.3046 €
100 mΩ
±1 %
SMD 2512 (6330)
3 mm
6.45 mm
0.7 mm
-55 °C
170 °C
3 W
thick film
Resistor, thick film, SMD 2512 (6330), 50 mΩ, 3 W, ±1 %, CRA2512-FZ-R050ELF
Resistor, thick film, SMD 2512 (6330), 50 mΩ, 3 W, ±1 %, CRA2512-FZ-R050ELF
Order No.:
 07E2926
Manufacturer:
 Bourns Electronics GmbH
Manufacturer SKU:
 CRA2512-FZ-R050ELF
Available: 3,433 pcs. Leadtime: 14 Weeks **
Total Price: 0.62 € *
1 pcs.
0.6188 €
50 pcs.
0.4522 €
250 pcs.
0.3689 €
500 pcs.
0.3332 €
1000 pcs.
0.3046 €
50 mΩ
±1 %
SMD 2512 (6330)
3 mm
6.45 mm
0.7 mm
-55 °C
170 °C
3 W
thick film
Resistor, thick film, SMD 2512 (6330), 20 mΩ, 3 W, ±1 %, CRA2512-FZ-R020ELF
Resistor, thick film, SMD 2512 (6330), 20 mΩ, 3 W, ±1 %, CRA2512-FZ-R020ELF
Order No.:
 07E2922
Manufacturer:
 Bourns Electronics GmbH
Manufacturer SKU:
 CRA2512-FZ-R020ELF
Available: 3,912 pcs. Leadtime: 14 Weeks **
Total Price: 5.83 € *
10 pcs.
0.5831 €
50 pcs.
0.4760 €
250 pcs.
0.4046 €
1000 pcs.
0.3451 €
2500 pcs.
0.3070 €
20 mΩ
±1 %
SMD 2512 (6330)
3 mm
6.45 mm
0.7 mm
-55 °C
170 °C
3 W
thick film
Resistor, thick film, SMD 2512 (6330), 10 mΩ, 3 W, ±1 %, CRA2512-FZ-R010ELF
Resistor, thick film, SMD 2512 (6330), 10 mΩ, 3 W, ±1 %, CRA2512-FZ-R010ELF
Order No.:
 07E2920
Manufacturer:
 Bourns Electronics GmbH
Manufacturer SKU:
 CRA2512-FZ-R010ELF
Available: 7,605 pcs. Leadtime: 14 Weeks **
Total Price: 0.62 € *
1 pcs.
0.6188 €
50 pcs.
0.4522 €
250 pcs.
0.3689 €
500 pcs.
0.3332 €
1000 pcs.
0.3046 €
10 mΩ
±1 %
SMD 2512 (6330)
3 mm
6.45 mm
0.7 mm
-55 °C
170 °C
3 W
thick film
