CLI-S 100/60 | Block
Enamel insulated copper wire, 60 x 0.1 mm, 0.11 kg, Block CLI-S 100/60
Enamelled copper stranded wire, CLI-S 100/45, BLOCK
Lacquer-insulated high-frequency copper litz wires for the production of coils and windings in the high-frequency range and for general laboratory use.
The HF litz consists of enamel-insulated wires twisted together with a common textile covering.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Insulating varnish | polyurethane | |
| Cable structure | 60 x 0.1 mm | |
| Outer diameter | 1.2 mm | |
| Max. current | 1.68 A | |
| Heat resistance | 155 °C | |
| Weight | 110 g | |
| Length | 22 m |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85441110 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
