CU-TIW 100/0,20 | Block

Copper wire, CU-TIW, 1 x 0.2 mm, transparent, outer Ø 0.417 mm, CU-TIW 100/0,20

Order No.: 89F100
EAN: 4099891168544
MPN:
CU-TIW 100/0,20
Series: CU-TIW
CU-TIW 100/0,20 Block Insulated stranded wires Image 1
CU-TIW 100/0,20 Block Insulated stranded wires Image 2
Image may differ
Unit Price (€ / pc.)
108.0996 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
108.10 € *
Price list
Quantity
Price per unit*
1 pcs.
108.0996 €
5 pcs.
99.9957 €
10 pcs.
91.8799 €
50 pcs.
86.4892 €
100 pcs.
81.0747 €
*incl. VAT plus shipping costs
Subject to prior sale

TEX-E wire, CU-TIW 100/0,20, BLOCK

TEX-E wires are used as insulated winding wires in switching power supply transformers, no additional insulation between primary and secondary necessary, solderable without previous stripping.

Technical specifications
Filter Property Value
Colour transparent
Cable material copper, bright
Test voltage 3 kV
Outer diameter 0.417 mm
Temperature range (active) up to 130 °C
Cable structure 1 x 0.2 mm
Rated voltage 1 kV
Logistics
Property Value
Customs tariff number 85441110
Country of origin JP
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
