99 0718 73 13 | binder

Angle coupling, 12 pole + PE, solder connection, screw locking, angled, 99 0718 73 13

Order No.: 70P0904
EAN: 4099891700744
MPN:
99 0718 73 13
Series: 694
99 0718 73 13 binder Other Circular Connectors Image 1
99 0718 73 13 binder Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
37.9967 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
38.00 € *
Price list
Quantity
Price per unit*
1 pcs.
37.9967 €
10 pcs.
35.7238 €
25 pcs.
33.2367 €
50 pcs.
30.8924 €
*incl. VAT plus shipping costs
Subject to prior sale

Female angled connector, 99 0718 73 13, binder

RD30 Female angled connector, Contacts: 12+PE, 14.0-18.0 mm, unshielded, solder, IP65.

Technical specifications
Version angle coupling
Cable cross-section 1.0 mm²
Pin number 12 pole + PE
Orientation angled
Contact connection solder connection
Type of locking screw locking
Cable diameter 14 to 18 mm
Assembly cable assembly
Additional parts equipped
contact surface silver-plated
Shell Material PA
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free No
RoHS conform Yes
