09 0506 70 16 | binder

Name: Jack, 16 pole, solder connection, screw locking, straight, 09 0506 70 16
Brand: binder
SKU: 70P1552
Price: 30.69 EUR
Availability: OutOfStock

Jack, 16 pole, solder connection, screw locking, straight, 09 0506 70 16

Order No.: 70P1552

EAN: 4099891703653

MPN:

09 0506 70 16

Series: 723

Image may differ

Key Specification:

Version jack

Cable cross-section 0.25 mm²

Pin number 16 pole

Orientation straight

Contact connection solder connection

Show 14 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

30.6901 € *

Available: 0 pcs.

Leadtime: 2 Weeks **

Add to Cart

Total Price:

30.69 € *
