UPS DinRail LiFePO4, UPSI-2412DP3

Order No.: 70C1508
EAN: 4251877648833
MPN:
UPSI-2412DP3
Series: UPSI
UPSI-2412DP3 Bicker Elektronik UPS Image 1
UPSI-2412DP3 Bicker Elektronik UPS Image 2
Image may differ
Unit Price (€ / pc.)
629.51 € *
Available: 1 pcs.
Total Price:
629.51 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
629.51 €

UPS, UPSI-2412DP3, Bicker Elektronik

Maximum safety for your 24 VDC application In the field of uninterruptible power supply, our DC UPS systems can be used in a variety of applications for a wide range of industries: Industry 4.0, automation, medical and laboratory technology, transportation, traffic monitoring, energy, communication, vending, POS / payment systems, security technology and many more.

Features

  • Powerful 24 V DC USV (DIN rail version)
  • Integrated LiFePO4 battery
  • Up to 6000 cycles
  • Capacity 64 Wh
  • Intelligent input current detection
  • Regulated output voltage in battery mode
Technical specifications
Filter Property Value
Width 111 mm
Power 240 W
Length 131 mm
max. operating temperature 55 °C
Input voltage AC 22.8-30 VDC
min. operating temperature -20 °C
Output current 10 A
Height 157 mm
Output voltage DC 24 VDC
Logistics
Property Value
Country of origin DE
Customs tariff number 85044083
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
