TL38Y005000 | APEM
Toggle switch, 1 pole, groping, On-Off-(On), 0.4 VA/20 V AC/DC, gold-plated
Images may differ
Unit Price (€ / pc.)
8.6513 € *
Available: 100 pcs.
Next delivery: 100 pcs. on 2023-12-21
Leadtime: 16 Weeks **
Total Price:
8.65 € *
Quantity
Price per unit*
1 pcs.
8.6513 €
10 pcs.
7.6160 €
50 pcs.
7.0924 €
150 pcs.
6.7830 €
500 pcs.
6.4379 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Toggle switches, wash-proof, type APEM TL.
Subminiature version for PCB mounting, fully sealed, wash-proof, wave soldering resistant, no ultrasonic soldering; Grid: 2.54 mm. Housing: PBT. Lever: brass, nickel-plated, 5.3 mm length. Contacts and terminals: gold-plated brass. Sealing of the terminals: epoxy. Breaking capacity: max. 0.4 VA/20 V AC/DC. Contact resistance: max. 20 mohm. Insulation resistance: min. 1000 Mohm on 500 VAC. Dielectric strength between contacts/terminals and ground: 500 VRMS / 1000 VRMS. Operating temperatures: –30 to +85 °C.
With straight solder pins and bracket.
Technical attributes (type, number of poles, switching action OFF, ON, momentary on, momentary (M)): TL38Y005000, single-pole, ON-OFF-M
Technical specifications
| Connection | PCB connection | |
| Design | vertical | |
| illuminated | No | |
| Actuator colour | metal | |
| contact surface | gold-plated | |
| Pin number | 1 pole | |
| Latching switching function | groping | |
| Breaking capacity | 0.4 VA/20 V AC/DC | |
| Shift position | On-Off-(On) |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
