IPR1SAD6 | APEM
Vandal-proof pushbutton switch, 1 pole, red, unlit , 4 A/12 V, mounting Ø 13.6 mm, IP67, IPR1SAD6
Unit Price (€ / pc.)
17.8381 € *
Available: 23 pcs.
Total Price:
17.84 € *
Price list
Quantity
Price per unit*
1 pcs.
17.8381 €
10 pcs.
15.7199 €
50 pcs.
14.6251 €
150 pcs.
13.9825 €
500 pcs.
13.2804 €
*incl. VAT plus shipping costs
Subject to prior sale
Panel switch, IPR1SAD6, APEM
The IPR1SAD6 Panel Switch is the perfect combination of sleek design and functionality. With its round curved actuator, it adds a touch of elegance to any electronic device. The switch offers two electrical functions, allowing you to easily toggle between OFF and ON positions. The contacts are made of silver with a goldplated finish, ensuring reliable and long-lasting performance.
Features
- Latching action
- Compact
- Flat round actuator for optional marking
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | latching | |
| Pin number | 1 pole | |
| Actuator colour | red | |
| Breaking capacity | 4 A/12 V | |
| illuminated | No | |
| Printed | No | |
| Vandal-proof | Yes | |
| Connection | solder connection | |
| Design | round | |
| contact surface | gold-plated | |
| Installation diameter | 13.6 mm | |
| Wall thickness | 1.5-5.5 mm | |
| Protection class | IP67 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
