PBAR9AF6000 | APEM
Piezo switch, On-Off, mounting Ø 19 mm, unlit, IP68, PBAR9AF6000
Unit Price (€ / pc.)
28.3101 € *
Standard delivery time from the manufacturer is: 16 Weeks
Piezo switch, PBAR9AF6000, APEM
The PBAR9AF6000 switch is a versatile product with a wide range of electrical functions. With its durable design and high-quality materials, it ensures reliable performance for years to come. The switch also features flying leads for easy installation and connection to your electrical system.
Features
- Easy to clean metal surface
- Very long life expectancy
- Ring illumination
Technical specifications
| Switching Voltage (AC) | 24 V | |
| Installation diameter | 19 mm | |
| Degree of protection (IP) | IP68 | |
| switching current | 200 mA | |
| Switching Voltage (DC) | 24 V | |
| Connection | stranded wires | |
| Latching switching function | On-Off | |
| can be illuminated | No | |
| Color of body | red |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
