PBAR9AF0000N0S | APEM
Piezo switch, On-Off, mounting Ø 19 mm, illuminated, red, IP66, PBAR9AF0000N0S
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
56.6083 € *
Standard delivery time from the manufacturer is: On Request
Piezo switch, PBAR9AF0000N0S, APEM
FEATURES
- Easy to clean metal surface
- Very long life expectancy
- Multi-wire leads section
Technical Data
- Housing colour: natural
- Connection: Wire connection
- Switching current: 200 mA
- Degree of protection IP: IP66
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | On-Off | |
| Installation diameter | 19 mm | |
| illuminated | Yes | |
| Farbe der Beleuchtung | red | |
| Connection | stranded wires | |
| Color of body | natural | |
| Degree of protection (IP) | IP66 | |
| Switching Voltage (DC) | 6 V | |
| Switching Voltage (AC) | 24 V | |
| switching current | 200 mA | |
| Lighting voltage | 12 VDC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
