PBAR9AF2000 | APEM
Piezo switch, On-Off, mounting Ø 19 mm, unlit, IP68, PBAR9AF2000
Unit Price (€ / pc.)
28.3101 € *
Standard delivery time from the manufacturer is: 16 Weeks
Piezo switch, PBAR9AF2000, APEM
The PBAR9AF2000 switch is the perfect solution for your electrical needs. With its reliable electrical functions, you can trust that it will deliver exceptional performance every time. It offers a wide range of electrical functions to suit your specific requirements.
Features
- Easy to clean metal surface
- Very long life expectancy
- Ring illumination
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Switching Voltage (AC) | 24 V | |
| Installation diameter | 19 mm | |
| Degree of protection (IP) | IP68 | |
| switching current | 200 mA | |
| Switching Voltage (DC) | 24 V | |
| Connection | stranded wires | |
| Latching switching function | On-Off | |
| can be illuminated | No | |
| Color of body | black |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
