D45U-V3AA | ZF Switches and Sensors
Miniature snap-action switche, On-On, plug-in connection, pin plunger, 1 N, 16 (4) A/250 VAC, 10 (3) A/400 VAC, IP40, D45U-V3AA
Unit Price (€ / pc.)
1.5708 € *
Available: 4,799 pcs.
Available in 5 Days: 6,638 pcs. - if ordered today
Miniature Snap Switch, D45U-V3AA, ZF Switches and Sensors
Single pole miniature snap switch
Features
- Precise snap action switch
- Long life coil spring mechanism
- Standard and light force operating mechanism
- Protection class: IP40
- Various aux actuators
- Various terminal types
Technical specifications
| Filter | Property | Value |
|---|---|---|
| actuating force | 1 N | |
| Protection class | IP40 | |
| Latching switching function | On-On | |
| Shell Material | PET | |
| Breaking capacity | 16 (4) A/250 VAC, 10 (3) A/400 VAC | |
| Connection | plug-in connection | |
| Actuator | pin plunger | |
| Switching point | 14.7 mm ±0.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | UA |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
