434111050826 | Würth Elektronik eiSos
Short-stroke pushbutton, Form A (N/O), 50 mA/12 VDC, unlit , actuator (white), 260 g, SMD, 434111050826
Unit Price (€ / pc.)
0.6069 € *
Available: 46 pcs.
Available in 5 Days: 41,205 pcs. - if ordered today
Total Price:
0.61 € *
Price list
Quantity
Price per unit*
1 pcs.
0.6069 €
10 pcs.
0.5712 €
100 pcs.
0.5629 €
750 pcs.
0.5093 €
1500 pcs.
0.4320 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Breaking capacity | 50 mA/12 VDC | |
| Actuator colour | white | |
| Connection | SMD | |
| Latching switching function | Form A (N/O) | |
| Contact material | silver-plated | |
| actuating force | 260 g | |
| Width | 3.5 mm | |
| Height | 5 mm | |
| Length | 6 mm | |
| illuminated | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365011 |
| Country of origin | CN |
| MSL | MSL 1 |
| Original Packaging | Reel with 1,500 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
