74650094R | Würth Elektronik eiSos
PCB terminal, 8 pole, pitch 5.87 mm, 85 A, solder connection, 74650094R
Unit Price (€ / pc.)
4.4030 € *
Available: 50 pcs.
Available in 5 Days: 66,846 pcs. - if ordered today
Total Price:
4.40 € *
Price list
Quantity
Price per unit*
1 pcs.
4.4030 €
10 pcs.
4.1650 €
50 pcs.
3.6533 €
100 pcs.
3.3320 €
500 pcs.
2.9988 €
*incl. VAT plus shipping costs
Subject to prior sale
Application:
- Solderable high current Wire-to-Board connections with a focus on automated assembly
- Beneficial power supply in multi layer applications
- Robust, mechanical high current connections
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Depth | 3.5 mm | |
| Rated current | 85 A | |
| Height | 4 mm | |
| Assembly | THT | |
| Width | 10 mm | |
| Grid | 5.87 mm | |
| Connection | solder connection | |
| Pin number | 8 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369095 |
| MSL | MSL 1 |
| Original Packaging | Reel with 600 pieces |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
