1779405341 | Würth Elektronik eiSos
DC converter, 21.6-26.4 VDC, 2 W, 1 output, 5 VDC, 80 % efficiency, 1779405341
Unit Price (€ / pc.)
5.4740 € *
Available: 9 pcs.
Available in 5 Days: 16,252 pcs. - if ordered today
Total Price:
5.47 € *
Price list
Quantity
Price per unit*
1 pcs.
5.4740 €
10 pcs.
5.2955 €
25 pcs.
5.2003 €
50 pcs.
5.0813 €
75 pcs.
4.8552 €
*incl. VAT plus shipping costs
Subject to prior sale
Characteristics
- Industrial standard package and pin configuration
- Leaded through-hole package for easy manufacturing and prototyping
- Low conducted and radiated EMI
- Simple Design
- Stand alone solution
- UL60950 certified
Application:
- Data acquisition
- Test and measurement systems
- Interface and microcontroller supply
- Industrial controls
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 0.2 A | |
| Output voltage DC | 5 VDC | |
| Input voltage AC | 21.6-26.4 VDC | |
| Power | 2 W | |
| efficiency | 80 % | |
| Design | SIP-7 | |
| Isolation voltage | 3 kV | |
| Length | 19.65 mm | |
| Width | 7.05 mm | |
| Height | 10.16 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Bar with 25 pieces |
| Customs tariff number | 85423911 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead monoxide (lead oxide) |
