61800929321 | Würth Elektronik eiSos
D-Sub connector, 9 pole, standard, straight, solder connection, 61800929321
Unit Price (€ / pc.)
3.3796 € *
Available: 18 pcs.
Available in 5 Days: 38,485 pcs. - if ordered today
Total Price:
3.38 € *
Price list
Quantity
Price per unit*
1 pcs.
3.3796 €
50 pcs.
3.1178 €
100 pcs.
2.8084 €
250 pcs.
2.5942 €
500 pcs.
2.3919 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Type of locking | threaded bolts 4-40 UNC | |
| Version | socket header | |
| Contact connection | solder connection | |
| Attachment (rear panel) | through hole | |
| Grid | 2.77 mm | |
| Pin number | 9 pole | |
| Performance level | 1 | |
| Assembly | straight | |
| Pole image | standard |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| MSL | MSL 1 |
| Original Packaging | Tray with 50 pieces |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
