EPN231506F | WÖHRLE
Power supply, power supply, 12 to 15 VDC, 6.5 A, 120 W, EPN231506F
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
272.51 € *
Standard delivery time from the manufacturer is: 1 Week
DC power supply, EPN231506F, WÖHRLE
Single-phase power supply, primary frequency, primary voltage: 230V, output: 15 volts DC, power: 6.5.
Features
- Adjustable output voltage
- Continuous short-circuit proof with SELV requirements
- Integrated overtemperature and overvoltage protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | power supply | |
| Number of outputs | 1 | |
| Output current | 6.5 A | |
| Output voltage DC | 12 to 15 VDC | |
| Input voltage AC | 187-264 VDC | |
| Power | 120 W | |
| efficiency | 87 % | |
| Width | 77 mm | |
| Height | 126 mm | |
| Depth | 128 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CH |
| Customs tariff number | 85044083 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
