239 780 55 | Werma

Recessed LED light, Ø 50 mm, blue/green/red/white/yellow, 24 VDC, 239 780 55

Order No.: 32M3774
EAN: 4099891540999
MPN:
239 780 55
239.780.55
Series: 239
239 780 55 Werma Beacons Image 1
239 780 55 Werma Beacons Image 2
Image may differ
Unit Price (€ / pc.)
186.0208 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
186.02 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
186.0208 €

AS-i-LED signal beacons, type Werma 239.

Capable of signaling several states, with five colors, color control via AS interface; Voltage: 24 VDC. Current consumption: max. 100 mA. Signal view: LED permanent beacon. For panel mounting. Connection: Plug-in with screw terminals, max. 1.5 mm² fine wire. Degree of protection: IP 65. Operating temperatures: –20 to +50 °C.

Type: 239 780 55, LED signal beacon

Technical specifications
Filter Property Value
Colour clear
Installation diameter 22.5 mm
Rated current 100 mA
diameter 50 mm
Height 81 mm
Farbe der Beleuchtung blue/green/red/white/yellow
Version LED permanent light
Voltage 24 VDC
Logistics
Property Value
Country of origin DE
Customs tariff number 85311095
Compliance
Property Value
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
